Product Code |
Product Description |
Product Picture |
Info |
Product Position |
BOLSTER END CAP |
>> | positioned at the top and bottom of the bolster claddings to finish of internal face |
||
BOLSTER BAR FIXING KIT (break down code SCR011 washer - BFS001 screw) |
used to secure bolster bar to glazing bars |
|||
STANDARD GLAZING BAR TOP CAPS |
this is used to secure polycarbonate/glass to roof by clipping in to glazing bar |
|||
CHAMBERED GLAZING BAR TOP CAP Domed |
>> | this is used to secure polycarbonate/glass to roof by clipping in to glazing bar |
||
CHAMBERED STARTER BAR END CAP |
>> | This product is secured by screw on the bottom end of the transom glazing bar, Chambered only. |
||
CHAMBERED END CAP Gable |
>> | This product is secured by screw on the bottom end of the starter glazing bar. Chambered only. |
||
CHAMBERED GEORGIAN GLAZING BAR TOP CAP |
>> | this is used to secure polycarbonate/glass to roof by clipping in to glazing bar |
||
CHAMBERED GEORGIAN GLAZING BAR END CAP |
>> | This product is secured by screw on the bottom end of the Georgian glazing bar. Chambered only. |
||
CHAMBERED STARTER BAR TOP CAP |
>> | this is used to secure polycarbonate/glass to roof by clipping in to glazing bar |
||
CHAMBERED GLAZING BAR TOP CAP Bevel |
>> | this is used to secure polycarbonate/glass to roof by clipping in to glazing bar |
||
CHAMBERED GLAZING BAR END CAP Domed |
>> | This product is secured by screw on the bottom end of the starter glazing bar. Chambered only. |
||
DECORATIVE GLAZING BAR CLADDING Standard Decorative |
>> | This is the glazing bar underclad situated on the inside of the roof. These are for splayed bars only |
||
DECORATIVE END CAP ROSE MOTIF |
>> | push fit into the chambered end cap series |
||
GLASS SUPPORT CLIP KIT 5 x pairGlass clips are black in colour |
>> | these are to secure the glass on the roof (glass only) |
||
POLYCARBONATE SUPPORT CLIP KIT 5 x pair |
>> | these are to secure the glass on the roof (polycarbonate only) |
||
END CAP FIXING SCREW |
>> | to be used in conjunction with the chambered end cap. |
||
FIRRING PIECE CAPPING Use with LCTB |
>> | sits directly between the starter bar and the gable frame on a gable roof |
||
GLAZING BAR UNDERCLADDING Standard |
>> | This is the glazing bar underclad situated on the inside of the roof. |
||
GLAZING BAR TOP CAP REMOVAL TOOL |
>> | Used to release the glazing bar top cappings from the glazing bars. |
||
JACK RAFTER KITS |
>> | used to connect jack rafter bars to Edwardian hip bars |
||
LEAN TO CLOAKING TRIM |
>> | cloaks of the starter bar and gable frame. Positioned outside of conservatory |
||
BOLSTER BAR Aluminium |
>> | screwed to the underside of the glazing bar and gives structural strength |
||
BOLSTER BAR PVC CLADDING |
>> | clicked onto the bolster bar as a cover |
||
STANDARD GLAZING BAR END CAPS - TRANSOM AND HIP BARSREMEDIALS ONLY |
>> | used with chambered bevelled and capa's. secured at bottom end of bar with screw. Fixing plate included |
||
STANDARD GLAZING BAR END CAPS - STARTERREMEDIALS ONLY |
>> | used with chambered dome and capa's. secured at bottom end of bar with screw. |
||
STANDARD GLAZING BAR END CAPS REMEDIALS ONLY |
>> | used with chambered dome and capa's. secured at bottom end of bar with screw. Fixing plate included |
||
7 SERIES STARTER BAR Light |
>> | to be used with the under claddings (against walls and gables) |
||
7 SERIES STARTER BAR Medium |
>> | to be used with the under claddings (against walls and gables) |
||
7 SERIES STARTER BAR Heavy |
>> | to be used with the under claddings (against walls and gables) |
||
7 SERIES GEORGIAN BAR Light |
>> | to be used with the under claddings (Georgian roofs) |
||
7 SERIES GEORGIAN BAR Heavy |
>> | to be used with the under claddings (Georgian roofs) |
||
7 SERIES TRANSOM / VICTORIAN Light |
>> | to be used with the under claddings (Victorian roofs) |
||
7 SERIES TRANSOM / VICTORIAN Medium |
>> | to be used with the under claddings (Victorian roofs) |
||
7 SERIES TRANSOM / VICTORIAN Heavy |
>> | to be used with the under claddings (Victorian roofs) |
||
GEORGIAN STRUCTURAL REINFORCEMENT Steel use JRKA004/1 (screw) to secure |
>> | slides in the Georgian glazing bar x 2 and secured by screws |
||
TRANSOM STRUCTURAL REINFORCEMENT Steel use JRKA004/1 (screw) to secure |
>> | slides in the transom glazing bar x 2 and secured by screws |
||
ANCHOR CLIPS |
>> | to stop the glazing bar top caps slipping down the glazing bars |
||
ROUTER BIT FOR ANCHOR CLIPS |
>> | Used to route out the hole required for the anchor clips |
||
JIG FOR ANCHOR CLIPS |
N/A |
>> | Required for the drilling of anchor clips |
