Product Code

Product description

Product Picture

Info

Product Position

BOLSTER END CAP

positioned at the top and bottom of the bolster claddings to finish of internal face

BOLSTER BAR FIXING KIT

used to secure bolster bar to glazing bars

STANDARD GLAZING BAR TOP CAPS

this is used to secure polycarbonate/glass to roof by clipping in to glazing bar

CHAMBERED GLAZING BAR TOP CAP (DOMED)

this is used to secure polycarbonate/glass to roof by clipping in to glazing bar

CHAMBERED STARTER BAR END CAP

This product is secured by screw on the bottom end of the transom glazing bar, Chambered only.

CHAMBERED END CAP (GABLE)

This product is secured by screw on the bottom end of the starter glazing bar. Chambered only.

CHAMBERED GEORGIAN GLAZING BAR TOP CAP

this is used to secure polycarbonate/glass to roof by clipping in to glazing bar

CHAMBERED GEORGIAN GLAZING BAR END CAP

This product is secured by screw on the bottom end of the Georgian glazing bar. Chambered only.

CHAMBERED STARTER BAR TOP CAP

this is used to secure polycarbonate/glass to roof by clipping in to glazing bar

CHAMBERED GLAZING BAR TOP CAP (BEVEL)

this is used to secure polycarbonate/glass to roof by clipping in to glazing bar

CHAMBERED GLAZING BAR END CAP (DOME)

This product is secured by screw on the bottom end of the starter glazing bar. Chambered only.

DECORATIVE GLAZING BAR CLADDING (ROUND)

This is the glazing bar underclad situated on the inside of the roof. These are for splayed bars only

DECORATIVE END CAP ROSE MOTIF

push fit into the chambered end cap series

GLASS SUPPORT CLIP KIT (5 X PAIR) NOTE: GLASS CLIPS ARE BLACK IN COLOUR

these are to secure the glass on the roof

DECORATIVE GLAZING BAR CLADDING (SQUARE)

This is the glazing bar underclad situated on the inside of the roof. These are used for jack rafters

POLYCARBONATE SUPPORT CLIP KIT (5 X PAIR)

these are to secure the glass on the roof

END CAP FIXING SCREW

to be used in conjunction with the chambered end cap.

FIRRING PIECE CAPPING (USE WITH LCTB)

sits directly between the starter bar and the gable frame on a gable roof

GLAZING BAR UNDERCLADDING (STANDARD)

This is the glazing bar underclad situated on the inside of the roof.

GLAZING BAR TOP CAP REMOVAL TOOL

Used to release the glazing bar top cappings from the glazing bars.

LEAN TO CLOAKING TRIM

cloaks of the starter bar and gable frame. Positioned outside of conservatory

BOLSTER BAR (ALUMINIUM)

screwed to the underside of the glazing bar and gives structural strength

BOLSTER BAR PVC CLADDING

clicked onto the bolster bar as a cover

STANDARD GLAZING BAR END CAPS - TRANSOM AND HIP BARS

used with chambered dome and capa's. secured at bottom end of bar with screw. Fixing plate included

STANDARD GLAZING BAR END CAPS - STARTER

used with chambered dome and capa's. secured at bottom end of bar with screw.

STANDARD GLAZING BAR END CAPS gable ended roofs only

used with chambered dome and capa's. secured at bottom end of bar with screw. Fixing plate included

7 SERIES STARTER BAR (LIGHT)

to be used with the under claddings (against walls and gables)

7 SERIES STARTER BAR (HEAVY)

to be used with the under claddings (against walls and gables)

7 SERIES GEORGIAN BAR (LIGHT)

to be used with the under claddings (Georgian roofs)

7 SERIES GEORGIAN BAR (HEAVY)

to be used with the under claddings (Georgian roofs)

7 SERIES TRANSOM / VICTORIAN (HEAVY)

to be used with the under claddings (Victorian roofs)

7 SERIES TRANSOM / VICTORIAN (LIGHT)

to be used with the under claddings (Victorian roofs)

GEORGIAN STRUCTURAL REINFORCEMENT (STEEL) Use JRKA004/1 (screw) to secure

slides in the Georgian glazing bar x 2 and secured by screws

TRANSOM STRUCTURAL REINFORCEMENT (STEEL) use JRKA004/1 (screw) to secure

slides in the transom glazing bar x 2 and secured by screws
